High-Precision Automatic Weighing and Packaging Machine

  • Air pressure 0.4-0.8 Mpa
  • Electric voltage 220V 50Hz / 60Hz
  • Power 3.5 KW
  • Capacity 5-50 pakge / min
  • Applicable Packaging Materials OPP / CPP / PE etc. Heat-Sealable Laminated Film

This weighing and packaging machine is specifically engineered for automated packaging environments where strict weight accuracy is paramount. At its core, the machine features a high-precision weighing module that performs accurate packaging based on the actual measured weight of each product.

For heavier materials, the machine incorporates a specialized bottom support structure designed to cushion the impact as material drops — ensuring the packaging bag retains its shape and remains free from deformation even under heavy load.

Highly versatile and compatible with a wide range of common heat-sealable composite films including OPP, CPP and PE. Bag length can be adjusted directly via the display screen or precisely controlled using a photoelectric sensor to track print marks for accurate cutting. Ideally suited for hardware accessories (metal clips, washers, fasteners) and various loose granular materials.

⚖️
High-Precision Weighing
High-precision weighing module ensures every packaged unit meets exact weight specifications
👜
Bag Shape Protection
Bottom support design prevents bag stretching and deformation when packaging heavy items
🎛️
Flexible Control
Bag length adjustable via display screen or photoelectric sensor for precise cutting

Technical Specifications
Packaging Speed 5–30 bags / min (subject to actual material)
Packaging Materials OPP / CPP / PE heat-sealable laminated film
Film Width Max. 520 mm
Bag Length Up to 300 mm (double-pull; adjustable via screen)
Bag Width 50–250 mm (changeable via bag former swap)
Metering Method Light curtain counting or straight-rail positioning
Sealing Mode Back seal or three-side seal
Seal Texture Straight-line / cross-hatch / flat (smooth)
Seal Width 10 mm (customizable)
Cutting Method Patterned-edge blade or fine-toothed blade
Air Exhaust Pinhole perforation or sponge compression
Air Pressure 0.4–0.8 MPa
Voltage 220V, 50Hz / 60Hz
Power 3.5 kW

Optional Auxiliary Equipment
Checkweigher In-line weight verification after packaging
Coding Machine Date, batch, and product code printing
Finished Product Conveyor Automated downstream product transfer
